Flywheel Grinder FGX-10A

Built to last from solid, cast iron, the FGX series Flywheel Grinder is designed to MAKE YOU MONEY! A flywheel grinder is a specialized machine tool used to resurface the friction surface of flywheels, which are crucial components in automotive and industrial engines. The flywheel is a heavy, rotating disc that helps store and release energy, aiding in the smooth operation of the engine by maintaining consistent speed and power delivery. Over time, the friction surface of the flywheel can become worn, grooved, or damaged due to repeated engagement and disengagement of the clutch. WVN Flywheel Grinder will restore flatness, improve performance, extended component life, help with cost-effective maintenance, provide precision and accuracy, and is versatile for resurfacing other components, such as pressure plates and brake rotors, making them versatile tools in an automotive shop.

Request A Quote

Fill out the form below to request a quote for the Flywheel Grinder FGX-10A.
Request Quote

Dimensions

Electrical

Production

Contact Info

Product Information

Designed for set-it-and-forget-operation, FGX flywheel grinders keep both labor and supply costs to a bare minimum. Set up is fast and accurate, and most pieces are completed within five to ten minutes. FGX flywheel grinders are highly productive and easy on your operating budget.

Part number : WVN945007

HP : 10

POWERHEAD : Yes

AUTO FEED : Yes

DESCRIPTION/ELECTRICALS : 208/230V, 60Hz, 3 Ph
AMP SERVICE REQUIRED : 35
MINIMUM WIRE SIZE : 12

Stainless Steel Coolant Tank
Extra Precise Grinding Dial
Digital Amp Meter for
Spark-Out Control
Wheel Dresser
Radius Cutter
Modern Redesigned Electrical
Stainless Grinding Shround
Precision Ball Screw and Linear Guiderail
Long Life Oil Bath Table Support

ITEM  PART #  DESCRIPTION
1    945305    Centering Cone Bolt 1.875″ (47.6 mm)
2   945306   Centering Cone Bolt 2.375″ (60.3 mm)
3   945307   Centering Cone Bolt 3.375″ (87.8 mm)
4   945323   Centering Cone 1″-1.75″ (25.4-44.5 mm)
5   945324   Centering Cone 1.312″-2″ (33.3-50.8 mm)
6   945325   Centering Cone 1.75″-2.5″ (44.5-63.5 mm)
7   801793    Centering Cone 2″-2.625″ (50.8-66.7 mm)
8   945326   Centering Cone 2.25″-3″ (57.2-76.2 mm)
9   945327    Centering Cone 2.75″-3.5″ (69.9-88.9 mm)
10  945341   Flange Adaptor 3″ (76.2 mm)
11  945342   Flange Adaptor 4″ (101.6 mm)
12  945343   Flange Adaptor 5″ (127 mm)
13  945344   Flange Adaptor 5.875″ (149.2 mm)
14  945204   Wheel Spacer 1.5″ (38.1mm)
15  801128   Grinding Wheel 4″ (101.6 mm) Flaring Cup
16  801112   Grinding Wheel 6″ (152.4 mm) Flaring Cup
17  801030  Grinding Wheel 6″ (152.4 mm) Flaring Cup
18  945200  Lower Wheel Flange
19  945097   E-Z Lok Inserts(2)
20  801152   LeadscrewLubricant
21  830001   Coolant Additive, 1 Qt (.946 liter)
22  801155   Table Lubricant, 2 Qts(.946 liter)
23  945345   Leveling Bolts(4)
24  945346   Leveling Bolt Lock Nuts(4)
25  945347   Leveling Pads(4)
26  945348   E-Z Lok Insert Extractor
27  945349   Table Oil Level Gage
28  945351   T-Handle HexWrench
29  945352   Wrench Set
30  945353   Wheel Mounting Bolt, 2.75″
31  945354   Wheel Mounting Bolt, 2.50″
32  945355   Wheel Mounting Bolt, 1.25″
33  945356   Wheel Mounting Bolt, 1.00″
34  945099   O-Ring

Technical Specifications

Table Diameter
16”
406.4 mm
Flywheel Diameter Capacity
24”
609.6 mm
Grinding Motor Power
10 HP
Grinding Motor Speed
35 RPM
Vertical Travel w/2.5” Wheel
8.75”
225.25 mm
Coolant Capacity, Std.
10 gal
38 L
Coolant Flow per Minute
19.5 gal
74 L
Height, Overall
67”
1702 mm
Height to Table
34.5”
876.3 mm
Space Required
35” x 38”
889 x 965.2 mm
Shipping weight
1500lbs
680.4 Kg
