Dust Collector Cartridge DCC-15-A

Category: Cartridge Dust Collectors, Dust Collectors

The Winona Van Norman DCC-15-A is a 5,000 cfm cartridge dust collector. The Winona Van Norman DCC-15-A uses eight cartridges to collect dust and debris from shot blasting and other industrial applications.

Request A Quote

Fill out the form below to request a quote for the Dust Collector Cartridge DCC-15-A.
Request Quote

Dimensions

Electrical

Production

Contact Info

Product Information

STD Filter Part Number: 903287
Washable Filter Part Number (optional): 903374
Special Features Included
Filter Removal Rack: N/A
Silencer: Optional
Hepa Filter: Optional
Rain Hood/Outdoor Kit: Optional
Fire Suppression System: Optional
Explosion Vent: Optional
Maintenance/Service Platform: Optional

Technical Specifications

Overall Dimensions (L x W x H)
86 in x 50 in x 156 in
2184 x 1270 x 3962 mm
Number of Cartridges/Filters
8
Filter Area
1784 (sq. ft.)
Blower
15 HP
Approx. Blower
5000 CFM
Approx. Shipping Weight
2475 lbs.
1122 kg
Duct Size
16 in
406 mm
Approx. Air Velocity
3583 ft./min.
1092 m/min
Gallon Size for Dust
55 Gal
208.2 L
