Ultrasonic ULS860
The Winona Van Norman ULS860 Ultrasonic Washer is engineered to deliver high-capacity, industrial-grade precision cleaning for oversized engine components and high-volume production applications. Utilizing multiple synchronized 28 kHz ultrasonic transducer banks, the ULS860 generates millions of microscopic cavitation bubbles that penetrate intricate passages, blind holes, and complex geometries to remove oils, grease, carbon, machining residue, and other contaminants without damaging delicate surfaces. Its extra-large stainless steel tank easily accommodates engine blocks, transmission housings, cylinder heads, and batches of smaller components, making it an ideal solution for engine rebuilding, remanufacturing, aerospace, and industrial manufacturing facilities.
Built for demanding production environments, the ULS860 features heavy-duty stainless steel construction, a thermally insulated tank and lid, and an integrated filtration and oil separation system that continuously removes contaminants to extend solution life and maintain peak cleaning performance. Replaceable 1 kW ultrasonic transducer arrays simplify maintenance while ensuring dependable long-term operation. Programmable touchscreen controls, adjustable wash cycles, automatic Eco Mode, and integrated water level and safety sensors provide precise process control and repeatable cleaning results with minimal operator intervention.
Designed for professional machine shops and high-volume industrial facilities, the Winona Van Norman ULS860 Ultrasonic Washer combines advanced ultrasonic technology, exceptional cleaning capacity, and low-maintenance operation to maximize productivity while reducing labor and operating costs. With its powerful cavitation cleaning, rugged construction, and consistently repeatable performance, the ULS860 delivers the precision cleaning results professionals rely on shift after shift.
Request A Quote
Product Information
Operations
The method of cleaning parts by the high-frequency sonic waves that induce a phenomenon called cavitation makes it possible to clean parts with all shapes, sizes and technical complexities, penetrating holes and cavities that are nearly impossible to reach using other methods.
Specifications
The most effective cleaning in heavy-duty applications
Cleans openings less than 0.04″
Modular design that adapts to your production line
No damage to parts or equipment
Maintains a clean work environment
Nonabrasive method
Easy to use & low maintenance
Less detergent consumption and waste treatment
Savings on labor cost as the machine is competitive
Robust heavy duty design
Complements your existing processes
80% of time savings
Features
Oil separation with custom LS fluid dynamics of laminar flow.
Green label features : insulated & perimeter sealed top lid – 2″ thermal & acoustic insulation – automatic nightly eco mode.
Digital & synchronized 28 Hz generators with sweep frequency programs for higher performance and smoother cavitation.
Replaceable 1 kW transducers sets. (screwed assembly at all sizes from 4 gal.)
Floating/PEEK water sensor level to protect heating system from boil-dry.
Insulated top lid.
Standard Tooling
Features and Options
Tank Dimensions:
Tank Capacity:
Loading Tray Dimensions:
Ultrasonic Power:
Heating Power:
Max. Lift Load:
Automatic Top Lid:
66.9″ l x 62.6″ d x 46.8″ h
859 Gallons
62″ h x 52.5″ w
10 kW
22 kW
2,205 lbs.
Included
